4,4'-DINITRODIPHENIC ACID (STELLAR-2020) [UNDER DEVELOPMENT]

1. STRUCTURE

2. PRODUCT NAME & DETAILS
Product Name	4,4'-Dinitrodiphenic acid (Stellar-2020) [Under Development]
Product Code	010726
CAS No	20246-81-5
HS Code	2917.39.90
Molecular Formula	C14H8N2O8
Molecular Wt.	332.22

3. Regulatory Information
Chemical name	Common names and synonyms	CAS number	EC number
2-(2-carboxy-4-nitrophenyl) -5-nitrobenzoic acid	4,4'-dinitro-[1,1'-biphenyl]-2,2' -dicarboxylic acid	20246-81-5	--
European Inventory of Existing Commercial Chemical Substances (EINECS)			Not Listed
EC Inventory			Not Listed
United States Toxic Substances Control Act (TSCA) Inventory			Not Listed
China Catalog of Hazardous chemicals 2015			Not Listed
Chinese Chemical Inventory of Existing Chemical Substances (China IECSC)			Not Listed
Korea Existing Chemicals List (KECL)			Not Listed
Canadian Domestic Substance List (DSL)			Not Listed
Canadian Non-Domestic Substance List (NDSL)			Not Listed
Japanese Existing and New Chemical Substances Inventory(ENCS)			Not Listed

4. SPECIFICATION
Physical Appearance	White to yellow powder or crystals
Purity	NLT 97%
Melting point	258-259 °C
Loss on drying	NMT 0.50%

5. APPLICATION

It is used in manufacturing liquid crystal display element.

6. HAZARD CLASSIFICATION

Non-Hazardous substance.

Irritant

7. ANNUAL CAPACITY

5 MT.

8. STORAGE CONDITION

Store in closed container at ambient temperature. Avoid direct sun light.

9. PACKING DETAILS

20 kg net in corrugated box with two PE liners, strip sealed separately.

10. SHELF LIFE

2 years.

Disclaimer
Typical properties should not be considered as specification. Product covered by valid patents are not offered or supplied for commercial use. The Patent position should be verified by the customer. Products will not be supplied to countries where they could be in conflict with existing patents. Products currently covered by valid US patents are offered for R&D use in accordance with 35 USC 271 (e) (I) Above information is given in good faith and without warrenty.

Disclaimer

Typical properties should not be considered as specification.
Product covered by valid patents are not offered or supplied for commercial use. The Patent position should be verified by the customer.
Products will not be supplied to countries where they could be in conflict with existing patents.
Products currently covered by valid US patents are offered for R&D use in accordance with 35 USC 271 (e) (I) Above information is given in good faith and without warrenty.
